100-C09E400 Allen-Bradley IEC Contactor 9A 4-Pole NO 380V AC Coil Screw Terminal

Description:

• Allen-Bradley IEC contactor designed for reliable motor switching and industrial control applications
• Rated at 9 Amps (AC-3) with 4 Normally Open (4 NO) main contacts
• Equipped with a 380V AC 60 Hz coil for industrial control circuits
• Screw terminal connections provide secure wiring and easy installation
• Compact IEC design supports DIN rail or panel mounting
• Suitable for switching motors, lighting loads, heaters, and other industrial electrical loads
• High-performance contact system delivers long electrical and mechanical service life
• Expandable with auxiliary contact blocks and accessories for increased control flexibility
• Ideal for motor control centers, machinery, OEM equipment, conveyors, and industrial automation
• Discontinued by Rockwell Automation; replacement models are available within the 100-E series.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 100-C09E400
• Product Series: Bulletin 100-C IEC
• Product Type: IEC Contactor
• Rated Operational Current (AC-3): 9 A
• Main Contacts: 4 Normally Open (4 NO)
• Auxiliary Contacts: None
• Coil Voltage: 380 VAC, 60 Hz
• Maximum Rated Operational Voltage: 690 VAC
• Terminal Type: Screw Terminals
• Mounting Type: 35 mm DIN Rail or Panel Mount
• Protection Rating: IP20
• Application: Motor Control, Industrial Machinery, OEM Equipment, HVAC Systems, Conveyors, and Industrial Automation
• Lifecycle Status: Discontinued (Replacement Available)

Dimensions:

• Height: 81 mm
• Width: 45 mm
• Depth: 86.5 mm

Weight:

• Approximate Weight: 0.40 kg (0.88 lb)
