1734-OBV2S Allen-Bradley POINT Guard I/O Safety Output Module 24VDC 4-Point

Description

• Allen-Bradley POINT Guard I/O safety digital output module
• 4 bipolar safety outputs arranged as 2 pairs
• 24 VDC industrial safety I/O module
• Supports sourcing and sinking outputs
• Dual-channel operation supports redundant safety control
• Safety outputs support pulse testing for field-wiring fault detection
• Designed for POINT Guard I/O and GuardLogix safety applications
• Suitable for machine guarding, emergency-stop and industrial safety systems
• Active Rockwell Automation product

Specifications

• Manufacturer: Allen-Bradley / Rockwell Automation
• Part Number: 1734-OBV2S
• Series: POINT Guard I/O
• Product Type: Safety Digital Output Module
• Outputs: 4 Points / 2 Bipolar Pairs
• Output Type: Current Sourcing / Current Sinking
• Power Supply: 24 VDC
• Field Power: 19.2–28.8 VDC
• Maximum Output Current: 1.25 A per output/bipolar pair at 40°C
• Maximum Aggregate Output Current: 2.0 A at 40°C
• Short-Circuit Detection: Yes
• Short-Circuit Protection: Electronic
• Reaction Time: <6.2 ms
• Operating Temperature: -20°C to +55°C
• Functional Safety: Up to SIL CL3 / PLe, Category 4 in appropriate dual-channel configurations
• Country of Origin: United States, according to Rockwell's current product listing
• UPC: 889508136127

Dimensions

• Refer to manufacturer specifications for exact dimensions

Weight

• Refer to manufacturer specifications for exact weight
