1769-ECR Allen-Bradley CompactLogix Right End Cap Terminator Compact I/O

Description:

• Genuine Allen-Bradley CompactLogix right end cap (terminator) for 1769 Compact I/O systems
• Required to terminate the right end of a 1769 Compact I/O bank, ensuring proper backplane communication and system operation
• Designed for use with CompactLogix and compatible MicroLogix 1500 expansion I/O systems using 1769 modules
• Prevents communication faults by properly terminating the local Compact I/O bus
• Compact snap-on design allows quick installation and removal during system assembly or maintenance
• Rugged industrial construction for long-term reliability in harsh industrial environments
• Mounts directly to the last 1769 I/O module in the assembly
• Suitable for machine automation, OEM equipment, process control, manufacturing systems, and industrial control panels
• Active Mature lifecycle status from Rockwell Automation.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 1769-ECR
• Product Series: CompactLogix / 1769 Compact I/O
• Product Type: Right End Cap / Terminator
• Function: Terminates the right end of the 1769 Compact I/O bus
• Compatible Systems:
  • CompactLogix Controllers
  • 1769 Compact I/O Systems
  • MicroLogix 1500 with 1769 Expansion I/O
• Mounting Location: Right side of the last 1769 I/O module
• Current Draw:
  • 5 mA @ 5.1 VDC
  • 0 mA @ 24 VDC
• Operating Temperature: 0°C to +60°C (32°F to +140°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Relative Humidity: 5–95% Non-Condensing
• Mounting Style: Snap-On
• Enclosure Type: Open Style
• Country of Origin: Malaysia
• Lifecycle Status: Active Mature
• Certifications:
  • UL
  • CE
  • ATEX
  • IECEx
  • UKCA
• Applications:
  • PLC Systems
  • Industrial Automation
  • Machine Control
  • Process Control
  • OEM Equipment
  • Control Panels

Dimensions:

• Height: 118 mm (4.65 in)
• Width: 32 mm (1.26 in)
• Depth: 18 mm (0.71 in)

Weight:

• Approximate Weight: 0.13 kg (0.29 lb).
