FL SWITCH SF 8TX Allen-Bradley Industrial Ethernet Switch 8-Port 10/100Mbps DIN Rail

Description:

• Industrial unmanaged Ethernet switch for reliable factory automation and machine networking
• Features 8 RJ45 Fast Ethernet ports supporting 10/100 Mbps with automatic speed detection
• Auto-Negotiation and Auto-MDI/MDIX (Auto-Crossing) simplify installation and commissioning
• Store-and-forward switching architecture provides reliable network communication
• DIN rail mounting design for industrial control panels and automation cabinets
• Dual redundant 24 VDC power inputs improve system reliability
• Integrated status LEDs for power, link, activity, and network diagnostics
• Rugged aluminum housing designed for harsh industrial environments
• Ideal for EtherNet/IP networks, PLCs, HMIs, drives, remote I/O, machine automation, and industrial control systems
• Manufactured by Phoenix Contact and commonly used in Allen-Bradley industrial Ethernet applications.

Specifications:

• Manufacturer Name: Phoenix Contact
• Model: FL SWITCH SF 8TX
• Product Type: Industrial Unmanaged Ethernet Switch
• Number of Ports: 8 × RJ45
• Ethernet Speed: 10/100 Mbps
• Switching Method: Store-and-Forward
• Auto Negotiation: Yes
• Auto MDI/MDIX: Yes
• Power Supply: 24 VDC (Redundant Inputs)
• Power Consumption: 4.8 W
• Mounting Type: DIN Rail
• Housing Material: Aluminum
• Protection Rating: IP20
• Operating Temperature: 0°C to +55°C
• Maximum Cable Length: 100 m per RJ45 port
• Certifications: UL, cUL, CE
• Application: Industrial Ethernet Networks, PLC Systems, HMIs, Variable Frequency Drives, Machine Automation, Factory Automation, Process Control.

Dimensions:

• Width: 135 mm
• Height: 94.3 mm
• Depth: 30 mm.

Weight:

• Approximate Weight: 0.42 kg (0.92 lb).
