100-K05D01 Allen-Bradley IEC Miniature Contactor 5A 3-Pole 110VAC 1NC Screw Terminal

Description:

• Genuine Allen-Bradley IEC miniature contactor for industrial motor control and automation applications
• Rated for 5A operation with 3 Normally Open (3 NO) main contacts and 1 Normally Closed (1 NC) auxiliary contact
• Equipped with a 110V AC 50Hz / 120V AC 60Hz control coil
• Compact design ideal for motor starting, switching resistive loads, lighting, HVAC systems, and industrial control circuits
• Features screw-type terminals for secure and reliable wiring
• Panel mount or 35 mm DIN rail mount installation for flexible integration into control panels
• Compatible with optional Allen-Bradley overload relays, surge suppressors, auxiliary contacts, timers, and mechanical interlocks
• Designed for industrial automation, OEM machinery, conveyor systems, packaging equipment, and machine control applications
• Part of the Allen-Bradley Bulletin 100-K IEC Miniature Contactor family with a compact footprint and long mechanical life.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 100-K05D01
• Product Series: Bulletin 100-K
• Product Type: IEC Miniature Contactor
• Rated Operational Current: 5 A
• Number of Poles: 3
• Main Contacts: 3 Normally Open (3 NO)
• Auxiliary Contacts: 1 Normally Closed (1 NC)
• Control Coil Voltage:
  • 110 VAC, 50 Hz
  • 120 VAC, 60 Hz
• Terminal Type: Screw Terminals
• Mounting:
  • 35 mm DIN Rail
  • Panel Mount
• Rated Insulation Voltage:
  • 690 VAC (IEC)
  • 600 VAC (UL/CSA)
• Rated Impulse Withstand Voltage: 6 kV
• Protection Rating: IP2X
• Maximum Altitude: 2000 m
• Mechanical Life: 15 Million Operations
• Applications:
  • Motor Control
  • Industrial Automation
  • HVAC Equipment
  • Machine Control
  • OEM Equipment
  • Control Panels
  • Conveyor Systems

Dimensions:

• Compact IEC miniature contactor designed for 35 mm DIN rail or panel mounting.
• Uniform mounting dimensions for easy replacement and installation.

Weight:

• Approximate Weight: 0.20 kg (0.44 lb).
