1489-A3C100 Allen-Bradley 10A 3-Pole Miniature Circuit Breaker C-Curve UL489 DIN Rail

Description:

• Genuine Allen-Bradley miniature circuit breaker designed for industrial branch circuit and control panel protection
• Provides 3-pole, 10 Amp overcurrent protection for three-phase AC electrical systems
• C-Curve trip characteristic ideal for circuits with moderate inrush currents, including motors, transformers, contactors, and industrial control equipment
• Rated for 480Y/277 VAC (UL/CSA) and 415 VAC (IEC) applications
• Thermal-magnetic trip mechanism provides dependable overload and short-circuit protection
• Compact 35 mm DIN rail mounting for quick installation in industrial control panels
• UL 489 Listed branch circuit protector for industrial and commercial electrical systems
• Finger-safe housing enhances installation and maintenance safety
• Ideal for industrial automation, machine control, OEM equipment, motor control centers, and electrical distribution systems
• Discontinued by Rockwell Automation. Replacement catalog number: 1489-M3C100.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 1489-A3C100
• Product Series: Bulletin 1489-A
• Product Type: Miniature Circuit Breaker (MCB)
• Number of Poles: 3
• Rated Current: 10 A
• Trip Curve: C
• Protection Type: Thermal-Magnetic
• Rated AC Voltage:
  • 480Y/277 VAC (UL/CSA)
  • 415 VAC (IEC)
• Rated Frequency: 50/60 Hz
• Interrupt Rating:
  • 10 kA (UL 489 / CSA)
  • 15 kA Icu (IEC 60947-2)
• Mounting Type: 35 mm DIN Rail
• Degree of Protection:
  • IP20 (Front)
  • IP00 (Terminals)
• Operating Temperature: -30°C to +60°C
• Certifications:
  • UL 489 Listed
  • CSA Certified
  • CE
  • IEC 60947-2
• Lifecycle Status: Discontinued
• Replacement: 1489-M3C100
• Applications:
  • Industrial Control Panels
  • Branch Circuit Protection
  • Motor Control
  • Machine Automation
  • OEM Equipment
  • Electrical Distribution

Dimensions:

• Height: 111 mm (4.37 in)
• Width: 52.5 mm (2.07 in)
• Depth: 74 mm (2.91 in).

Weight:

• Approximate Weight: 0.37 kg (0.82 lb).
