1756-ENBT Allen-Bradley ControlLogix EtherNet/IP Communication Module 10/100Mbps RJ45 Ethernet Bridge

Description:

• Genuine Allen-Bradley ControlLogix EtherNet/IP communication module for industrial Ethernet networking and PLC communication
• Provides 10/100 Mbps EtherNet/IP communication through a single RJ45 Ethernet port
• Supports EtherNet/IP, TCP/IP, and CIP messaging for seamless integration with ControlLogix, CompactLogix, HMIs, drives, and remote I/O
• Supports up to 64 TCP connections and 128 CIP connections for explicit and implicit messaging
• Installs in any slot of a ControlLogix chassis for flexible system configuration
• Compatible with Studio 5000 Logix Designer and RSLogix 5000 programming software
• Ideal for PLC communication, remote I/O, SCADA systems, HMI integration, industrial networking, and machine automation
• Discontinued by Rockwell Automation; recommended replacement is the 1756-EN2T EtherNet/IP communication module.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 1756-ENBT
• Product Series: ControlLogix
• Product Type: EtherNet/IP Communication Module
• Communication Protocol: EtherNet/IP
• Ethernet Interface: 1 × RJ45 10/100 Mbps
• Communication Speed: 10/100 Mbps
• Maximum TCP Connections: 64
• Maximum CIP Connections: 128
• Ethernet Ports: 1
• Current Draw:
  • 700 mA @ 5.1 VDC
  • 3 mA @ 24 VDC
• Power Dissipation: 3.7 W
• Thermal Dissipation: 12.6 BTU/hr
• Isolation Voltage: 30V Continuous
• Mounting Type: ControlLogix Chassis (Any Slot)
• Operating Temperature: 0°C to +60°C (32°F to 140°F)
• Storage Temperature: -40°C to +85°C (-40°F to 185°F)
• Relative Humidity: 5–95% Non-Condensing
• Protection Rating: Open Style
• Certifications:
  • UL Listed
  • CE
  • ATEX
  • China CCC
  • RCM
• Country of Origin: United States
• Applications:
  • Industrial Ethernet Networks
  • PLC Systems
  • Remote I/O
  • SCADA
  • HMI Communication
  • Process Control
  • Machine Automation
  • Manufacturing Systems

Dimensions:

• Height: 145 mm (5.71 in)
• Width: 38 mm (1.50 in)
• Depth: 140 mm (5.51 in).

Weight:

• Approximate Weight: 0.32 kg (0.71 lb).
