1794-IV16 Allen-Bradley FLEX I/O 16-Point 24VDC Digital Input Module Source Input

Description:

• Genuine Allen-Bradley FLEX I/O digital input module for distributed industrial I/O systems
• Provides 16 sourcing digital input channels for 24 VDC field devices
• Designed for use with FLEX I/O adapters including EtherNet/IP, ControlNet, DeviceNet, and Remote I/O systems
• Supports 24 VDC nominal input voltage with a 10...31.2 VDC operating range
• Features individual LED status indicators for each input channel to simplify diagnostics
• Compact modular design allows easy expansion of FLEX I/O systems
• Supports Removal and Insertion Under Power (RIUP) when used with compatible FLEX I/O systems
• DIN rail mounted using a compatible FLEX terminal base (sold separately)
• Ideal for PLC automation, packaging equipment, material handling, process control, machine automation, and industrial control panels
• Manufactured by Rockwell Automation with Active Mature lifecycle status.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 1794-IV16
• Product Series: FLEX I/O
• Product Type: Digital Input Module
• Number of Inputs: 16
• Input Type: 24 VDC Sourcing (NPN)
• Nominal Input Voltage: 24 VDC
• Input Voltage Range: 10...31.2 VDC
• Current Consumption: 11 mA per input (typical)
• Isolation: Non-Isolated Inputs
• Status Indicators: Individual Input LEDs
• Mounting Type: DIN Rail (requires FLEX terminal base)
• Operating Temperature: 0°C to +55°C (32°F to 131°F)
• Power Supply: 24 VDC
• Compatible Terminal Bases: 1794-TB2, 1794-TB3, 1794-TBN and other compatible FLEX bases
• Certifications: UL Listed, CSA Certified, CE
• Country of Origin: Singapore
• Application: Distributed I/O, PLC Systems, Industrial Automation, Machine Control, Packaging, Material Handling, Process Control.

Dimensions:

• Height: 94 mm (3.70 in)
• Width: 63 mm (2.48 in)
• Depth: 69 mm (2.72 in).

Weight:

• Approximate Weight: 0.11 kg (0.24 lb).
