100-K05D01 Allen-Bradley IEC Miniature Contactor 5A 3-Pole 110/120VAC Coil 1NC Screw Terminal

Description:

• Genuine Allen-Bradley IEC miniature contactor for industrial motor control and automation applications
• Provides 3 Normally Open (3 NO) main contacts with 1 Normally Closed (1 NC) auxiliary contact
• Rated for 5A operational current, ideal for switching motors, control circuits, lighting, and industrial loads
• Equipped with a 110 VAC 50 Hz / 120 VAC 60 Hz control coil
• Compact IEC design saves panel space while delivering reliable switching performance
• Screw terminal connections provide secure and dependable wiring
• Suitable for 35 mm DIN rail or panel mounting
• Compatible with Allen-Bradley Bulletin 100-K accessories including overload relays, surge suppressors, auxiliary contacts, timers, and mechanical interlocks
• Ideal for industrial automation, machine control, HVAC equipment, packaging machinery, conveyors, and OEM equipment
• Part of the Allen-Bradley Bulletin 100-K IEC Miniature Contactor family.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 100-K05D01
• Product Series: Bulletin 100-K
• Product Type: IEC Miniature Contactor
• Rated Operational Current: 5 A
• Number of Poles: 3
• Main Contacts: 3 Normally Open (3 NO)
• Auxiliary Contacts: 1 Normally Closed (1 NC)
• Control Coil Voltage:
  • 110 VAC, 50 Hz
  • 120 VAC, 60 Hz
• Terminal Type: Screw Terminals
• Mounting Type:
  • 35 mm DIN Rail
  • Panel Mount
• Rated Insulation Voltage:
  • 690 VAC (IEC)
  • 600 VAC (UL/CSA)
• Rated Impulse Withstand Voltage: 6 kV
• Protection Rating: IP2X
• Mechanical Life: 15 Million Operations
• Operating Temperature: -25°C to +60°C
• Applications:
  • Motor Control
  • Industrial Automation
  • Machine Control
  • HVAC Equipment
  • OEM Equipment
  • Packaging Machinery
  • Conveyor Systems

Dimensions:

• Height: 58 mm (2.28 in)
• Width: 45 mm (1.77 in)
• Depth: 57 mm (2.24 in).

Weight:

• Approximate Weight: 0.20 kg (0.44 lb).
