800H-R Allen-Bradley 30mm Momentary Push Button Operator Round Booted Heavy-Duty Industrial

Description:

• Genuine Allen-Bradley Bulletin 800H heavy-duty 30 mm momentary push button operator for industrial control panels
• Round booted push button design provides added protection against dust and moisture
• Heavy-duty operator designed for use with compatible 800H contact blocks (sold separately)
• Rugged plastic construction engineered for demanding industrial environments
• 30.5 mm panel cutout for standard industrial control stations
• Compatible with NEMA Type 1, 4, 4X, 12, and 13 enclosures when properly installed
• Screw terminal compatibility through matching 800H contact blocks
• Ideal for machine automation, motor control, OEM equipment, process control, conveyors, and industrial control panels
• Available in multiple colors and contact configurations depending on the complete catalog number (e.g., 800H-R1AY, 800H-R7, etc.)

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Product Series: Bulletin 800H
• Base Part Number: 800H-R
• Product Type: Momentary Push Button Operator
• Operator Style: Round Booted Push Button
• Operator Function: Momentary
• Panel Cutout Diameter: 30.5 mm
• Operator Material: Synthetic Rubber Boot with Plastic Operator
• Mounting Type: Panel Mount
• Mechanical Life: 10,000,000 Operations
• Electrical Connection: Compatible with screw-terminal contact blocks
• Compatible Contact Blocks: Bulletin 800H / 800T Contact Blocks
• Enclosure Compatibility:
  • NEMA 1
  • NEMA 4
  • NEMA 4X
  • NEMA 12
  • NEMA 13
• Operating Temperature: -25°C to +55°C
• Certifications:
  • UL Listed
  • CSA Certified
  • CE
  • CCC
  • EAC
• Applications:
  • Industrial Control Panels
  • Machine Automation
  • Motor Control
  • OEM Equipment
  • Process Automation
  • Manufacturing Systems

Dimensions:

• Panel Cutout: 30.5 mm (1.20 in)
• Standard Bulletin 800H operator dimensions for 30 mm mounting.

Weight:

• Approximate Weight: 0.15 kg (0.33 lb)
