100-K05D01 Allen-Bradley IEC Miniature Contactor 5A 3-Pole 110/120VAC Coil 1NC

Description:

• Genuine Allen-Bradley Bulletin 100-K IEC miniature contactor for industrial motor control and automation applications
• Rated for 5A operational current with 3 Normally Open (3 NO) main contacts
• Includes 1 Normally Closed (1 NC) built-in auxiliary contact
• Equipped with a 110 VAC 50 Hz / 120 VAC 60 Hz control coil
• Compact design ideal for switching motors, contactors, lighting, HVAC equipment, and industrial control circuits
• Features screw-clamp terminals for secure, vibration-resistant wiring
• Mounts on a 35 mm DIN rail or panel for flexible installation
• Compatible with Allen-Bradley 100-K overload relays, auxiliary contacts, surge suppressors, and mechanical interlocks
• Designed for industrial automation, machine building, conveyor systems, OEM equipment, packaging machinery, and control panels
• Active product in the Allen-Bradley Bulletin 100-K miniature contactor family.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 100-K05D01
• Product Series: Bulletin 100-K
• Product Type: IEC Miniature Contactor
• Rated Operational Current: 5 A
• Number of Poles: 3
• Main Contacts: 3 Normally Open (3 NO)
• Auxiliary Contacts: 1 Normally Closed (1 NC)
• Control Coil Voltage:
  • 110 VAC, 50 Hz
  • 120 VAC, 60 Hz
• Terminal Type: Screw Clamp
• Mounting:
  • 35 mm DIN Rail
  • Panel Mount
• Rated Insulation Voltage:
  • 690 VAC (IEC)
  • 600 VAC (UL/CSA)
• Rated Impulse Withstand Voltage: 6 kV
• Protection Rating: IP2X
• Mechanical Life: 15 Million Operations
• Operating Temperature: -25°C to +60°C
• Certifications:
  • UL
  • CSA
  • CE
  • UKCA
• Applications:
  • Motor Control
  • Industrial Automation
  • HVAC Systems
  • Machine Control
  • OEM Equipment
  • Conveyor Systems
  • Control Panels

Dimensions:

• Compact IEC miniature contactor designed for 35 mm DIN rail or panel mounting.
• Standard Bulletin 100-K footprint for easy replacement and installation.

Weight:

• Approximate Weight: 0.20 kg (0.44 lb).
