18900001 ASCO Joucomatic 3/2 Normally Closed Solenoid Valve 110VAC 50Hz / 120VAC 60Hz Pad Mount

Description:

• Genuine ASCO Joucomatic direct-operated solenoid valve for pneumatic and industrial automation applications
• 3/2-way, normally closed (NC) valve designed for reliable control of compressed air and inert gases
• Operates on 110 VAC 50 Hz / 120 VAC 60 Hz with a low 2.5 W power consumption
• Direct-acting design provides fast response without requiring a minimum operating pressure
• Pad-mounted configuration for compact installation in valve manifolds and pneumatic systems
• Features NBR (Nitrile Butadiene Rubber) seals for dependable performance with air and compatible fluids
• Compact engineered plastic body offers corrosion resistance and long service life
• DIN electrical connection simplifies installation and maintenance
• Ideal for industrial automation, pneumatic machinery, packaging equipment, process control, OEM systems, and valve manifold assemblies.

Specifications:

• Manufacturer Name: ASCO Joucomatic (Emerson)
• Part Number (MPN): 18900001
• Product Type: Solenoid Valve
• Valve Function: 3/2-Way Normally Closed (NC)
• Valve Operation: Direct Operated
• Mounting Style: Pad Mount
• Coil Voltage:
  • 110 VAC, 50 Hz
  • 120 VAC, 60 Hz
• Power Consumption: 2.5 W
• Orifice Size: 3/64 in (1.2 mm)
• Flow Coefficient (Cv): 0.05
• Maximum Operating Pressure: 10 bar (145 psi)
• Minimum Operating Pressure: 0 bar
• Maximum Fluid Temperature: 60°C (140°F)
• Ambient Temperature Range: -10°C to +60°C
• Seal Material: NBR (Nitrile)
• Body Material: Engineered Plastic (PA+FV)
• Electrical Connection: DIN Connector
• Media: Compressed Air and Inert Gases
• Applications:
  • Pneumatic Automation
  • Valve Manifolds
  • Packaging Machinery
  • Industrial Automation
  • Process Control
  • OEM Equipment

Dimensions:

• Mounting Style: Pad Mount
• Orifice Size: 3/64 in (1.2 mm)
• Compact manifold-mount design for pneumatic systems.

Weight:

• Approximate Weight: 0.16 kg (0.35 lb).
