AT-FM-2A Banner DUO-TOUCH Two-Hand Control Safety Relay 24V AC/DC 2NO DIN Rail

$379.99 CAD

Sale Sold out

Style Refurbish

Description:

DUO-TOUCH two-hand control safety relay designed for industrial machine safeguarding applications
Monitors two-hand control push buttons to help prevent accidental machine operation
Operates on a universal 24V AC/DC power supply
Features two normally open (2 NO) force-guided safety outputs rated at 4A
Includes one normally closed (1 NC) auxiliary monitoring output rated at 0.5A
Self-checking circuitry continuously monitors relay operation for enhanced machine safety
Requires simultaneous two-button actuation within 500 ms for safe operation
Compact DIN rail mount design with fixed screw terminal connections
Suitable for presses, stamping equipment, assembly machinery, and industrial automation systems
Discontinued by Banner Engineering; ideal as a replacement or spare for existing DUO-TOUCH systems.

Manufacturer Name: Banner Engineering
Part Number (MPN): AT-FM-2A
Product Series: DUO-TOUCH AT Series
Product Type: Two-Hand Control Safety Relay
Supply Voltage: 24V AC/DC
Safety Inputs: Two-Hand Control (1 NPN + 1 PNP or Relay Contacts)
Safety Outputs: 2 Normally Open (2 NO), 4A
Auxiliary Output: 1 Normally Closed (1 NC), 0.5A
Simultaneity Requirement: 500 ms Maximum
Response Time: 25 ms Maximum
Mounting Type: DIN Rail
Terminal Type: Fixed Screw Terminals
Protection Rating: IP20
Housing Width: 45 mm
Application: Two-Hand Machine Control, Presses, Machine Safety, Industrial Automation
Status: Obsolete / Discontinued by Manufacturer
