BC3045S480 BEMAG 45 kVA 3-Phase Isolation Transformer 480V to 208Y/120V Dry Type

Description:

• Genuine BEMAG dry-type isolation transformer designed for industrial and commercial power distribution
• Rated at 45 kVA for reliable three-phase voltage transformation
• 480V primary to 208Y/120V secondary configuration for powering three-phase and single-phase loads
• Dry-type, air-cooled transformer suitable for indoor industrial applications
• Copper windings provide efficient power transfer and long service life
• Floor or wall mounting design for flexible installation
• Neutral available on the secondary for mixed three-phase and 120V branch circuits
• Ideal for manufacturing facilities, commercial buildings, machine control, distribution panels, OEM equipment, and industrial automation
• Engineered for dependable voltage isolation, noise reduction, and electrical system protection.

Specifications:

• Manufacturer Name: BEMAG
• Part Number (MPN): BC3045S480
• Product Type: Dry-Type Isolation Transformer
• Power Rating: 45 kVA
• Phase: 3-Phase
• Transformer Type: Isolation
• Primary Voltage: 480 VAC
• Secondary Voltage: 208Y/120 VAC
• Frequency: 60 Hz
• Cooling Method: Air Cooled (AN)
• Winding Material: Copper
• Mounting:
  • Floor Mount
  • Wall Mount
• Neutral: Yes
• Enclosure: Industrial Steel Enclosure
• Applications:
  • Industrial Automation
  • Manufacturing Equipment
  • Distribution Panels
  • Machine Control
  • Commercial Buildings
  • OEM Equipment
  • Power Distribution Systems

Dimensions:

• Height: 22 in
• Width: 24 in
• Depth: 16 in

Weight:

• Approximate Weight: 346 lb (157 kg).
