BOS 23K-PU-RH10-S4 Balluff Diffuse Photoelectric Sensor PNP NO/NC 3-800mm M12 Background Suppression

Description:

• Genuine Balluff diffuse photoelectric sensor designed for reliable object detection in industrial automation applications
• Features background suppression (triangulation) technology for accurate detection regardless of background color or distance
• Adjustable sensing range from 3 mm to 800 mm
• PNP Normally Open / Normally Closed (NO/NC) switching output with selectable light-on/dark-on operation
• Uses a red LED light source with a focused beam for precise object detection
• Compact 23K series housing suitable for machine automation and OEM equipment
• M12 4-pin male connector for quick installation and reliable electrical connection
• Washdown-rated design suitable for demanding industrial and food processing environments
• Ideal for packaging machinery, conveyors, material handling, assembly systems, robotics, and factory automation
• Reliable performance with 10–30 VDC operating voltage and rugged industrial construction.

Specifications:

• Manufacturer Name: Balluff
• Part Number (MPN): BOS 23K-PU-RH10-S4
• Order Code: BOS0178
• Product Series: 23K
• Product Type: Diffuse Photoelectric Sensor
• Sensing Principle: Triangulation with Background Suppression
• Sensing Range: 3...800 mm
• Rated Sensing Distance: 800 mm (Adjustable)
• Output Type: PNP NO/NC
• Switching Function: Light-On / Dark-On
• Light Source: Red LED (640 nm)
• Beam Characteristic: Focused (Typical at 500 mm)
• Light Spot Size: 15 × 15 mm at focal point
• Operating Voltage: 10...30 VDC
• Connection: M12 × 1 Male, 4-Pin
• Housing Material: PC / ABS
• Sensing Surface Material: PMMA
• Dimensions: 23 × 51 × 52.4 mm
• Mounting: M4 Screw Mount
• Maximum Ambient Light: 5000 Lux
• Special Features:
  • Background Suppression
  • Washdown Design
  • Adjustable Sensing Distance
• Certifications:
  • CE
  • cULus
  • Ecolab
  • WEEE
• Applications:
  • Factory Automation
  • Packaging Equipment
  • Conveyor Systems
  • Material Handling
  • Robotics
  • Food & Beverage Equipment
  • OEM Machinery

Dimensions:

• Height: 23 mm
• Width: 51 mm
• Depth: 52.4 mm

Weight:

• Approximate Weight: 0.12 kg (0.26 lb).
