CIMR-J7AZ22P2 Omron Varispeed J7 Variable Frequency Drive 2.2kW 3HP 200-230VAC 3-Phase VFD

Description:

• Genuine Omron Varispeed J7 variable frequency drive (VFD) for precise AC motor speed and torque control
• Rated for 2.2 kW (3 HP) three-phase induction motors
• Designed for 200–230 VAC, 3-phase input power systems
• Delivers 230 VAC three-phase output with a rated output current of 11 A
• Utilizes PWM V/f control for smooth acceleration, deceleration, and reliable motor performance
• Programmable output frequency from 0.1 to 400 Hz for flexible speed control
• Compact IP20 chassis-mount design for installation inside electrical control panels
• Built-in digital operator with potentiometer simplifies local setup and parameter adjustment
• Integrated protection functions include overload, overvoltage, undervoltage, overcurrent, overheating, and ground fault detection
• Ideal for conveyors, pumps, fans, mixers, packaging machinery, machine tools, HVAC equipment, and industrial automation systems
• Obsolete model; commonly used for maintenance and replacement of existing Varispeed J7 installations.

Specifications:

• Manufacturer Name: Omron
• Product Series: Varispeed J7
• Part Number (MPN): CIMR-J7AZ22P2
• Product Type: Variable Frequency Drive (VFD)
• Motor Rating: 2.2 kW (3 HP)
• Input Voltage: 200–230 VAC
• Input Phase: 3-Phase
• Input Frequency: 50/60 Hz
• Allowable Input Voltage Variation: -15% to +10%
• Allowable Input Frequency Variation: ±5%
• Output Voltage: 0–230 VAC (proportional to input voltage)
• Output Phase: 3-Phase
• Rated Output Current: 11 A
• Maximum Output Frequency: 400 Hz
• Control Method: PWM V/f Control
• Frequency Setting Resolution:
  • 0.01 Hz (<100 Hz)
  • 0.1 Hz (≥100 Hz)
• Mounting Type: Chassis Mount
• Enclosure Rating: IP20
• Operating Temperature: -10°C to +50°C
• Cooling Method: Forced Air
• Applications:
  • Pumps
  • Fans
  • Conveyors
  • Packaging Equipment
  • Mixers
  • Machine Tools
  • HVAC Systems
  • Industrial Automation

Dimensions:

• Height: 135 mm (5.3 in)
• Width: 127 mm (5.0 in)
• Depth: 114 mm (4.5 in)

Weight:

• Approximate Weight: 1.4 kg (3.0 lb)
