MS-OPS2-WH Lutron Maestro Occupancy Sensor Switch 120V 2A Single-Pole White

Description:

• Maestro occupancy sensor switch designed for automatic lighting control in residential and commercial applications
• Passive Infrared (PIR) sensor with exclusive Lutron XCT™ Technology for accurate major and minor motion detection
• Automatically turns lights ON when occupancy is detected and OFF after the selected timeout period
• Supports Occupancy, Vacancy, and Manual-ON operating modes
• Rated for 120 VAC, 2 Amp general-purpose loads
• Single-pole installation with no neutral wire required
• Adjustable timeout settings of 1, 5, 15, or 30 minutes
• 180° field of view with coverage up to 900 sq. ft. for major motion and 400 sq. ft. for minor motion
• Compatible with LED, incandescent, halogen, fluorescent, and fan loads within rated capacities
• Ideal for bathrooms, laundry rooms, garages, closets, utility rooms, offices, and other indoor spaces.

Specifications:

• Manufacturer Name: Lutron Electronics
• Part Number (MPN): MS-OPS2-WH
• Product Series: Maestro
• Product Type: Occupancy Sensor Switch
• Sensor Technology: Passive Infrared (PIR)
• Operating Modes: Occupancy, Vacancy, Manual-On
• Voltage Rating: 120 VAC
• Frequency: 50/60 Hz
• Current Rating: 2 A
• Mounting Type: Wall Box, Single-Pole
• Neutral Wire: Not Required
• Coverage Area:
  • Major Motion: Up to 900 sq. ft. (30 ft × 30 ft)
  • Minor Motion: Up to 400 sq. ft. (20 ft × 20 ft)
• Field of View: 180°
• Adjustable Timeout: 1, 5, 15, or 30 Minutes
• Color: White
• Indoor Use Only
• Certifications: UL Listed, cUL Listed
• Application: Automatic Lighting Control for Residential and Commercial Buildings.

Dimensions:

• Standard decorator wall switch size
• Fits standard single-gang electrical wall boxes
• Compatible with decorator wall plates.

Weight:

• Approximate Weight: 0.18 lb (0.08 kg).
