100-K05D01 Allen-Bradley IEC Miniature Contactor 5A 3-Pole 110/120VAC Coil 1NC

Description:

• Genuine Allen-Bradley Bulletin 100-K IEC miniature contactor for industrial motor control and automation applications
• Rated for 5A with 3 Normally Open (3 NO) main contacts and 1 Normally Closed (1 NC) auxiliary contact
• Equipped with a 110 VAC 50 Hz / 120 VAC 60 Hz control coil
• Compact IEC design ideal for switching motors, control circuits, lighting, HVAC equipment, and industrial machinery
• Screw terminal connections provide secure and reliable field wiring
• Supports both 35 mm DIN rail and panel mounting for flexible installation
• Compatible with Allen-Bradley 100-K series accessories, including overload relays, auxiliary contacts, surge suppressors, and mechanical interlocks
• Long mechanical life ensures dependable performance in demanding industrial environments
• Ideal for OEM machinery, conveyor systems, packaging equipment, motor starters, and industrial control panels
• Manufactured by Rockwell Automation for reliable industrial switching applications.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 100-K05D01
• Product Series: Bulletin 100-K
• Product Type: IEC Miniature Contactor
• Rated Operational Current (AC-3): 5 A
• Number of Poles: 3
• Main Contacts: 3 Normally Open (3 NO)
• Auxiliary Contacts: 1 Normally Closed (1 NC)
• Coil Voltage:
  • 110 VAC, 50 Hz
  • 120 VAC, 60 Hz
• Terminal Type: Screw Clamp
• Mounting Options:
  • 35 mm DIN Rail
  • Panel Mount
• Rated Insulation Voltage:
  • 690 VAC (IEC)
  • 600 VAC (UL/CSA)
• Rated Impulse Withstand Voltage: 6 kV
• Protection Rating: IP20
• Mechanical Life: 15 Million Operations
• Operating Temperature: -25°C to +60°C
• Applications:
  • Motor Control
  • Industrial Automation
  • Machine Control
  • HVAC Systems
  • Conveyor Systems
  • Packaging Equipment
  • OEM Machinery

Dimensions:

• Height: 77 mm (3.03 in)
• Width: 45 mm (1.77 in)
• Depth: 86 mm (3.39 in)

Weight:

• Approximate Weight: 0.20 kg (0.44 lb).
