6536G5 Edwards Signaling Mini Horn Strobe 24VAC/DC Call for Assistance Clear Lens

Description:

• Genuine Edwards Signaling mini horn/strobe designed for call for assistance and general audible/visual notification applications
• Combines an audible horn and high-intensity strobe in one compact unit
• Operates on 24 VAC (50/60 Hz) or 24 VDC
• Produces 92 dB at 1 meter (82 dB at 10 ft.) for clear audible notification
• Features a 50 candela clear xenon strobe for high-visibility signaling
• Designed for installation on a single-gang 2" × 4" electrical box or compatible mounting box
• Neutral white housing blends with commercial and institutional interiors
• UL 1638 Listed for visual signaling applications
• Ideal for hospitals, healthcare facilities, assisted living, schools, offices, public buildings, and industrial call-for-assistance systems
• Suitable for indoor audible and visual notification applications.

Specifications:

• Manufacturer Name: Edwards Signaling
• Part Number (MPN): 6536G5
• Product Series: CFA Series
• Product Type: Mini Horn Strobe
• Audible Signal: Horn
• Visual Signal: Xenon Strobe
• Sound Output:
  • 92 dB @ 1 m
  • 82 dB @ 10 ft
• Strobe Intensity: 50 Candela
• Lens Color: Clear
• Housing Color: Neutral White
• Operating Voltage:
  • 24 VAC, 50/60 Hz
  • 24 VDC
• Current Draw:
  • 0.175 A @ 24 VAC
  • 0.125 A @ 24 VDC
• Mounting:
  • Single-Gang Electrical Box
  • 2" × 4" Box
• Indoor Use: Yes
• Certifications:
  • UL 1638 Listed
• Applications:
  • Call for Assistance Systems
  • Nurse Call Systems
  • Audible & Visual Notification
  • Commercial Buildings
  • Healthcare Facilities
  • Industrial Facilities
  • Institutional Buildings

Dimensions:

• Height: 4.56 in (116 mm)
• Width: 4.50 in (114 mm)
• Projection: 2.25 in (57 mm)
• Wall Depth: 0.81 in (20 mm)

Weight:

• Approximate Weight: 0.21 kg (0.46 lb).
