17463500 Leeson SM2 Flux Vector VFD 7.5HP 480-590V 3-Phase NEMA 1 AC Drive

Description:

• Leeson SM2 Flux Vector Variable Frequency Drive (VFD) designed for demanding industrial motor control applications
• Rated for 7.5 HP (5.5 kW) with 480–590 VAC three-phase input and three-phase output
• Advanced open-loop flux vector control delivers excellent low-speed torque and precise motor speed regulation
• Supports Vector Speed, Vector Torque, Standard V/Hz, and Enhanced V/Hz operating modes
• NEMA 1 / IP31 enclosure for indoor industrial installations
• Built-in LED keypad simplifies programming, monitoring, and diagnostics
• Features PID control, auto-tuning, programmable digital and analog I/O, and dynamic braking capability
• Ideal for conveyors, pumps, fans, mixers, packaging machinery, material handling equipment, HVAC systems, and industrial automation
• Manufactured by Leeson (Regal Rexnord) for reliable and efficient motor control performance.

Specifications:

• Manufacturer Name: Leeson (Regal Rexnord)
• Part Number (MPN): 17463500
• Product Series: SM2 Flux Vector
• Product Type: Variable Frequency Drive (VFD)
• Motor Rating: 7.5 HP (5.5 kW)
• Input Voltage: 480–590 VAC
• Input Phase: 3-Phase
• Output Voltage: 480–590 VAC
• Output Phase: 3-Phase
• Continuous Output Current: 9 A
• Control Method: Open-Loop Flux Vector / V/Hz
• Output Frequency: 0–500 Hz
• Enclosure Rating: NEMA 1 / IP31
• Mounting Type: Panel Mount
• Display: LED Keypad
• Application: Pumps, Fans, Conveyors, Packaging Equipment, Material Handling, HVAC, Industrial Machinery, OEM Equipment.

Dimensions:

• Height: 9.83 in (250 mm)
• Width: 5.12 in (130 mm)
• Depth: 6.30 in (160 mm).

Weight:

• Approximate Weight: 7 lb (3.2 kg).
