MOELLER

NS2-160-NA Moeller Eaton 160A 3-Pole Molded Case Switch Disconnect UL489 IEC 60947-2

$1,249.99 CAD

Sale Sold out

STYLE REFURBISH

Description:

Genuine Moeller by Eaton molded case switch disconnect for industrial power distribution and isolation applications
Rated for 160A continuous current with 3-pole switching configuration
Designed as a molded case switch (non-overload protective disconnect) for safe isolation of electrical circuits
Suitable for use as a main disconnect switch, feeder disconnect, or branch circuit isolator
Features front screw terminals for secure and reliable field wiring
Part of the Eaton NZM Series with Frame J-K (N2) construction
Fixed-mounted design with rugged molded case housing for demanding industrial environments
Certified to UL 489, CSA C22.2 No. 5, and IEC 60947-2
Ideal for industrial automation, motor control centers, switchboards, OEM machinery, and electrical distribution systems
Designed for North American applications and compatible with Eaton NZM accessories including rotary handles, motor operators, and auxiliary contacts.

Manufacturer Name: Moeller by Eaton
Part Number (MPN): NS2-160-NA
Catalog Number: 102684
Product Series: NZM
Product Type: Molded Case Switch Disconnect
Rated Current: 160 A
Number of Poles: 3
Frame Size: N2 (Frame J-K)
Connection Type: Front Screw
Mounting Type: Fixed Mount
Rated Operational Voltage: Up to 690 VAC (IEC)
UL Maximum Voltage Rating:
- 480Y/277 VAC
- 600Y/347 VAC
Switching Capacity (SCCR):
- 100 kA @ 480Y/277 VAC
- 50 kA @ 600Y/347 VAC
Instantaneous Self-Protection Trip: 2500 A Fixed
Degree of Protection: IP20
Mechanical Life: 20,000 Operations
Operating Temperature: -25°C to +70°C
Storage Temperature: -40°C to +70°C
Standards:
- UL 489
- CSA C22.2 No. 5
- IEC 60947-2
- CE Marked
Applications:
- Main Disconnect Switch
- Industrial Control Panels
- Motor Control Centers
- Electrical Distribution
- OEM Equipment
- Industrial Automation
- Switchboards
