PC1104-L-R Ktech CP1100 Overfill Protection Device 120VAC 1/3HP Pump Control Panel with Low-Level Alarm

Description:

• Genuine Ktech Industrial Products Inc. CP1100 overfill protection and pump control panel
• Model PC1104-L-R designed to automatically control liquid level in a tank using a pump
• Operates on 120 VAC, 60 Hz, single-phase power
• Rated for pump loads up to 1/3 HP, 7.2A
• Designed for use with a Ktech FS301-3 float switch
• Three float-switch inputs provide pump stop, pump start, and low-level alarm functions
• HAND/OFF/AUTO selector allows manual operation, complete shutdown, or automatic liquid-level control
• Green pilot light indicates when the pump is operating
• Red pilot light provides visual indication of a LOW level alarm
• Integrated audible alarm provides 95 dB at 1 ft. with mute function
• Low-level alarm circuit automatically resets when the liquid level returns to normal
• Includes a dedicated relay contact output for the low-level alarm
• Suitable for industrial tanks, liquid storage systems, petroleum applications, process equipment, and automated pump systems
• Certified to CAN/ULC-S661-10.

Specifications:

• Manufacturer: Ktech Industrial Products Inc.
• Model / Part Number: PC1104-L-R
• Product Family: CP1100
• Product Type: Pump Control Panel / Overfill Protection Device
• Input Voltage: 120 VAC
• Frequency: 60 Hz
• Phase: Single Phase (1PH)
• Motor Rating: 1/3 HP
• Current Rating: 7.2 A
• Float Switch Compatibility: Ktech FS301-3
• Operating Modes:
  • HAND
  • OFF
  • AUTO
• Float Switch Inputs:
  • FS3-A – Pump Stop
  • FS3-B – Pump Start
  • FS3-C – Low-Level Alarm
• Switch Input Terminals:
  • 1 & 2
  • 3 & 4
  • 5 & 6
• Low Alarm Relay Output: Terminals 9 & 10
• Pump Control Output: Terminals 11 & 12
• Audible Alarm: 95 dB @ 1 ft.
• Alarm Type: Low Liquid Level
• Visual Indicators:
  • Power Indicator
  • Green Pump Running Indicator
  • Red Low-Level Alarm Indicator
• Certification: CAN/ULC-S661-10
• Applications:
  • Liquid Level Control
  • Tank Pump Control
  • Industrial Pump Systems
  • Petroleum Equipment
  • Storage Tanks
  • Process Control
  • Industrial Automation

How It Operates:

• In AUTO mode, the FS3-B float contact starts the pump when the liquid level drops
• The pump fills the tank until the liquid rises above the FS3-A stop point
• FS3-A then shuts the pump off
• If the liquid reaches the FS3-C low-level point, the panel activates the red alarm light and audible buzzer
• In HAND mode, the operator manually runs the pump
• In OFF mode, the pump cannot operate.

Dimensions:

• Enclosed industrial pump control panel
• Exact enclosure dimensions should be verified from the unit label or Ktech drawing before listing shipping dimensions

Weight:

• Exact manufacturer weight is not published on the Ktech product page
• Recommended: weigh the complete panel before entering Shopify shipping weight
