9002AW2 Schneider Electric Harmony Industrial Foot Switch SPDT Spring Return NEMA 4/13

Description:

• Genuine Schneider Electric Harmony industrial foot switch for hands-free machine and equipment control
• Features single-step operation with SPDT (1 NO + 1 NC) double-break contacts
• Spring return pedal automatically returns to the normal position after release
• Heavy-duty pedal and side shields help protect the operator from accidental activation
• Rated for 600 VAC/DC control circuits with industrial-grade switching performance
• NEMA 2, 4, and 13 enclosure suitable for harsh industrial environments
• 0.75 in. NPT conduit entry simplifies installation and wiring
• UL Listed and CSA Certified for industrial applications
• Ideal for machine tools, presses, welding equipment, packaging machinery, conveyors, and industrial automation systems.

Specifications:

• Manufacturer Name: Schneider Electric
• Brand: Harmony
• Part Number (MPN): 9002AW2
• Product Type: Industrial Foot Switch
• Contact Operation: 1 Step
• Contact Configuration: SPDT (1 NO + 1 NC)
• Contact Type: Double Break
• Operator Action: Spring Return
• Protection:
  • Pedal Shield
  • Side Shields
• Rated Voltage: 600 VAC/DC
• Rated Breaking Capacity:
  • 15A @ 120 VAC (Resistive)
  • 10A @ 240 VAC (Inductive)
  • 6A @ 480 VAC (Inductive)
  • 5A @ 600 VAC (Inductive/Resistive)
  • 0.5A @ 125 VDC (Resistive)
• Cable Entry: 0.75 in. NPT Conduit
• Enclosure Rating:
  • NEMA 2
  • NEMA 4
  • NEMA 13
• Certifications:
  • UL Listed
  • CSA Certified
• Country of Origin: Mexico
• Applications:
  • Machine Tools
  • Power Presses
  • Industrial Automation
  • Packaging Equipment
  • Material Handling
  • Manufacturing Systems
  • OEM Machinery

Dimensions:

• Height: 123 mm (4.84 in)
• Width: 137 mm (5.39 in)
• Depth: 229 mm (9.02 in)

Weight:

• Approximate Weight: 2.10 kg (4.64 lb).
