100-K05D01 Allen-Bradley IEC Miniature Contactor 5A 3-Pole 120VAC Coil 3NO + 1NC

Description:

• Genuine Allen-Bradley Bulletin 100-K IEC miniature contactor for industrial motor control and automation applications
• Rated for 5A AC-3 motor switching with 3 Normally Open (3 NO) main contacts and 1 Normally Closed (1 NC) auxiliary contact
• Equipped with a 120 VAC 50/60 Hz control coil for reliable operation in industrial control circuits
• Compact design saves panel space while providing dependable switching performance
• Screw-clamp terminals ensure secure and reliable field wiring connections
• Supports DIN rail or panel mounting for flexible installation
• Compatible with Allen-Bradley 100-K accessories including overload relays, auxiliary contact blocks, surge suppressors, timers, and mechanical interlocks
• Designed for controlling motors, pumps, compressors, fans, conveyors, HVAC equipment, and industrial machinery
• Ideal for OEM equipment, machine builders, industrial automation, and control panel applications
• Part of the Allen-Bradley Bulletin 100-K IEC miniature contactor family.

Specifications:

• Manufacturer Name: Allen-Bradley (Rockwell Automation)
• Part Number (MPN): 100-K05D01
• Product Series: Bulletin 100-K
• Product Type: IEC Miniature Contactor
• Rated Operational Current (AC-3): 5 A
• Number of Poles: 3
• Main Contacts: 3 Normally Open (3 NO)
• Auxiliary Contacts: 1 Normally Closed (1 NC)
• Coil Voltage: 120 VAC, 50/60 Hz
• Utilization Category: AC-3
• Terminal Type: Screw Clamp
• Mounting Type:
  • 35 mm DIN Rail
  • Panel Mount
• Rated Insulation Voltage: 690 VAC (IEC)
• Rated Impulse Withstand Voltage: 6 kV
• Protection Rating: IP2X
• Mechanical Life: 15 Million Operations
• Operating Temperature: -25°C to +60°C
• Certifications:
  • UL Recognized
  • CSA Certified
  • CE
  • IEC 60947
• Applications:
  • Motor Control
  • Industrial Automation
  • HVAC Systems
  • Machine Control
  • Conveyor Systems
  • OEM Equipment
  • Control Panels

Dimensions:

• Height: 58 mm (2.28 in)
• Width: 45 mm (1.77 in)
• Depth: 57 mm (2.24 in)

Weight:

• Approximate Weight: 0.21 kg (0.46 lb).
