5SY6208-8 Siemens SENTRON 8A 2-Pole Miniature Circuit Breaker D-Curve 400VAC 6kA DIN Rail

Description:

• Genuine Siemens SENTRON miniature circuit breaker for industrial and commercial electrical protection
• Provides 2-pole, 8 Amp overcurrent and short-circuit protection
• D-Curve trip characteristic designed for high inrush current loads, including motors, transformers, contactors, and inductive equipment
• Rated for 400 VAC operation with a 6 kA breaking capacity according to EN 60898-1
• Thermal-magnetic trip mechanism provides reliable overload and short-circuit protection
• Compact 35 mm DIN rail mounting for quick installation in distribution boards and industrial control panels
• Finger-safe terminals improve installation safety and simplify maintenance
• Suitable for industrial automation, OEM machinery, motor control panels, HVAC equipment, and electrical distribution systems
• Part of the Siemens SENTRON 5SY6 miniature circuit breaker family.

Specifications:

• Manufacturer Name: Siemens
• Part Number (MPN): 5SY6208-8
• Product Series: SENTRON 5SY6
• Product Type: Miniature Circuit Breaker (MCB)
• Number of Poles: 2
• Rated Current: 8 A
• Trip Curve: D
• Protection Type: Thermal-Magnetic
• Rated Operational Voltage:
  • 400 VAC
  • 230 VAC (Single Phase)
• Rated Frequency: 50/60 Hz
• Breaking Capacity:
  • 6 kA (EN 60898-1)
  • 15 kA (IEC 60947-2)
• Rated Insulation Voltage (Ui): 440 VAC
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• DC Voltage Rating: 60 VDC
• Maximum DC Operating Voltage: 72 VDC
• Energy Limitation Class: 3
• Degree of Protection: IP20 (with connected conductors)
• Mounting Type: 35 mm DIN Rail
• Mechanical Life: 10,000 Operations
• Standards:
  • EN 60898-1
  • IEC 60947-2
  • CE
• Applications:
  • Industrial Control Panels
  • Electrical Distribution
  • Motor Protection
  • HVAC Systems
  • OEM Equipment
  • Machine Automation

Dimensions:

• Width: 36 mm (2 modules)
• Depth: 70 mm
• Mounting: 35 mm DIN Rail

Weight:

• Approximate Weight: 0.31 kg (0.68 lb).
