8910DPA23V14 Square D Definite Purpose Contactor 25A 3-Pole 24VAC Coil 600VAC Open Type

Description:

• Genuine Square D by Schneider Electric definite purpose contactor for HVAC, refrigeration, and industrial motor control applications
• Rated 25 Amps with 3-pole (3 NO) main contacts for reliable switching of three-phase loads
• 24 VAC, 50/60 Hz control coil for dependable operation
• Rated for 600 VAC maximum operating voltage
• Compact open-frame design for panel-mounted installations
• Heavy-duty silver alloy contacts provide long electrical life and reliable switching
• Screw and quick-connect terminal options simplify installation and maintenance
• Suitable for compressors, pumps, fans, air conditioners, refrigeration systems, and industrial machinery
• UL Listed and CSA Certified for commercial and industrial applications
• Manufactured by Schneider Electric for dependable motor control performance.

Specifications:

• Manufacturer Name: Square D (Schneider Electric)
• Part Number (MPN): 8910DPA23V14
• Product Series: Class 8910 DPA
• Product Type: Definite Purpose Contactor
• Number of Poles: 3
• Main Contacts: 3 NO
• Rated Current: 25 A
• Coil Voltage: 24 VAC, 50/60 Hz
• Rated Operational Voltage: 600 VAC
• Horsepower Rating:
  • 2 HP @ 115V, 1-Phase
  • 5 HP @ 230V, 1-Phase
  • 10 HP @ 230V, 3-Phase
  • 15 HP @ 460V, 3-Phase
  • 20 HP @ 575V, 3-Phase
• Mounting Type: Panel Mount
• Terminal Type: Screw / Quick Connect
• Enclosure: Open Type
• Certifications: UL Listed, CSA Certified, CE
• Application: HVAC Equipment, Refrigeration Systems, Motor Starters, Pumps, Compressors, Industrial Machinery, OEM Equipment.

Dimensions:

• Height: 4.00 in (101.6 mm)
• Width: 2.50 in (63.5 mm)
• Depth: 3.12 in (79.2 mm).

Weight:

• Approximate Weight: 1.07 lb (0.49 kg).
